Specifications

AIMS SKU A0153866
Brand NACHI
Model Number 51324/NACHI
Da1 (max) 156
Outer Diameter D (mm) 210
D3 220
D2 165
D1 (min) 123
Basic Static Load Rating Coa (N) 870000
Basic Dynamic Load Rating Ca (N) 310000
r(min) 2.1
T4 80
T3 74.1
Da2 (max) 165
Bore Diameter x Outer Diameter x Width (mm) 120 x 210 x 70
Da (min) 174
D1 (max) 205
Width B (mm) 70
Bore Diameter d (mm) 120
S 22
R 160
A 63
Ra (max) 2
Oil Lubrication 1100
Grease Lubrication 790
• Type Spherical Roller Thrust Bearings
• Series 51100-51400
