Specifications

AIMS SKU A0067027
Brand KCM
Model Number 50SB/KCM
Chain Number 50SB
Pin A (mm) 10.35
Min Horizontal Bending Radius R 400
Max Allowable Load (kgf) 290
Max Allowable Load (kN) 2.84
Average Tensile Strength (kgf) 2100
Link Plate Height H (mm) 14.6
Link Plate Thickness T (mm) 2
Pin (A+B) L2 (mm) 22.65
Pin (A+A) L1 (mm) 20.7
Pin B (mm) 12.3
Pin Diameter d (mm) 4.51
Roller Diameter D (mm) 10.16
Width Between Inner Plates W (mm) 9.53
Pitch P (mm) 15.875
Chain Length 10 ft
Chain Pitch 5/8 in
Average Tensile Strength (kN) 20.6
Approximate Weight (kg/m) 0.98
• Type Roller Chain
• System of Measurement American (ASA)
• Strand Simplex
