Description

TechTop’s TAI aluminium series AC induction motors are suitable for all industrial applications where optimal design performance and low weight are key factors.

As standard, TechTop’s TAI series electric motors are fitted with detachable feet allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.

Minimum Energy Performance Standards (MEPS) Compliant

Specifications

  • AIMS SKU A0098281
  • Brand TechTop
  • Model Number TA6A0554TAI
  • Poles 6
  • IEC Frame Size 80 B
  • Mounting Position B3,B5
  • Base RPM 900
  • Shaft Diameter 19 mm
  • Mounting Type Foot & Flange Mounted
  • Group Code Techtop-TAI-0.55kw
  • Type Three Phase
  • Material Aluminium
  • Nominal Rated Input Voltage 415 V
  • Rated Load (kW) 0.55
  • Rated Load (HP) 3/4
  • Current Type AC
  • AC Phase Three Phase
  • Series Techtop TAI
SKU: A0098281

TechTop 0.55kW 3/4 HP Motor 415V 3 Phase 6 Pole, 900 RPM, Foot & Flange TA6A0554TAI

415V Three Phase Aluminium Motor (TA6A0554TAI)

$225.41
5/5 based on 1 review.
