Description

TechTop’s TML series AC induction motors are ideally suited for all general purpose applications where starting torque performance and low weight are key factors.

The TechTop TML series electric motor's flexibility in mounting arrangements makes it a perfect fit for aluminium gearbox applications.

Motors up to 2.2kW are fitted with manual reset overload

Specifications

  • AIMS SKU A0098017
  • Brand TechTop
  • Model Number TA2A0255TML
  • Poles 2
  • IEC Frame Size 63 B
  • Mounting Position B5
  • Base RPM 2710
  • Shaft Diameter 11 mm
  • Mounting Type Flange-Mounted
  • Group Code Techtop-TML-0.25kw
  • Type Single Phase
  • Material Aluminium
  • Nominal Rated Input Voltage 240 V
  • Rated Load (kW) 0.25
  • Rated Load (HP) 1/3
  • Current Type AC
  • AC Phase Single Phase
  • Series Techtop TML
SKU: A0098017

TechTop 0.25kW 1/3 HP Motor 240V 1 Phase 2 Pole, 2710 RPM, Flange Mount TA2A0255TML

240V Single Phase Cap Start/Cap Run Motor (TA2A0255TML)

$200.17
