Description

TechTop’s TAI aluminium series AC induction motors are suitable for all industrial applications where optimal design performance and low weight are key factors.

As standard, TechTop’s TAI series electric motors are fitted with detachable feet allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.

Minimum Energy Performance Standards (MEPS) Compliant

Specifications

  • AIMS SKU A0098497
  • Brand TechTop
  • Model Number TA6A0097TAI
  • Poles 6
  • IEC Frame Size 63 A
  • Mounting Position B14A
  • Base RPM 840
  • Shaft Diameter 11 mm
  • Mounting Type Flange-Mounted
  • Group Code Techtop-TAI-0.09kw
  • Type Three Phase
  • Material Aluminium
  • Nominal Rated Input Voltage 415 V
  • Rated Load (kW) 0.09
  • Rated Load (HP) 0.12
  • Current Type AC
  • AC Phase Three Phase
  • Series Techtop TAI
SKU: A0098497

TechTop 0.09kW 0.12 HP Motor 415V 3 Phase 6 Pole, 840 RPM, Flange Mount TA6A0097TAI

415V Three Phase Aluminium Motor (TA6A0097TAI)

$140.66
