TechTop 0.06 kW Motor 415V 3 Phase 4 Pole, 1370 RPM, Foot & Flange TA4A0068TAI

415V Three Phase Aluminium Motor (TA4A0068TAI)

No Reviews yet. Write a product review

Available
$72.19
$76.23
SAVE $4.04
zippay

Browse other products under:
Motors
Browse other products by:
TechTop

TechTop’s TAI aluminium series AC induction motors are suitable for all industrial applications where optimal design performance and low weight are key factors.

As standard, TechTop’s TAI series electric motors are fitted with detachable feet allowing for the motor feet to be repositioned to either side to produce a side mounted terminal box.

  • Aluminium Body
  • Wattage: 0.06kW
  • Poles: 4
  • Power: Three Phase (415V)
  • Mounting: Foot & Flange(B3/B14B)
  • Frame: 56 A
  • RPM: 1370
  • Shaft: 9mm
  • Full Load Amperage (FLA): 0.3A
  • Minimum Energy Performance Standards (MEPS) Compliant

Brand

TechTop

SKU

A0098573

Model #

TA4A0068TAI

Product Type

Three Phase Motor

Voltage

Three Phase (415V)

Power

0.06 kW

Material

Aluminium

Poles

4

Mounting

Foot & Flange Mounted (B3/B14B)

RPM

1300 to 1390 RPM

Shaft

9mm

Frame Size

56
