Specifications

AIMS SKU A0177890
Brand EZO
Model Number 634-2RSC3/EZO
Cage Type J
Ball Complement Qty Z (pcs) 7
Width B1 (in) 0.197
Width B1 (mm) 5.0
Width B (in) 0.197
Bore Diameter d inch 0.158
Bore Diameter d mm 4.0
Weight (Reference) 2 Shields (g) 5.2
Ball Complement Size Dw (in) 0.094
Ball Complement Size Dw (mm) 2.381
Bore Diameter x Outer Diameter x Width (mm) 4 x 16 x 5
Max Speed Oil (x1000min -1) 54
Max Speed Grease (x1000min -1) 46
Chamfer rs (min) (in) 0.012
Chamfer rs (min) (mm) 0.30
Outer Diameter D (in) 0.630
Load Rating Cor (N) 517
Load Rating Cr (n) 1340
Width B (mm) 5.0
Outer Diameter D (mm) 16.0
• Type Ball Bearing
• Series Type 630 Series
