Specifications

AIMS SKU A0177882
Brand EZO
Model Number 688-2RSC3/EZO
Cage Type J
Ball Complement Qty Z (pcs) 10
Width B1 (in) 0.197
Width B1 (mm) 5.0
Width B (in) 0.158
Bore Diameter d inch 0.315
Bore Diameter d mm 8.0
Weight (Reference) 2 Shields (g) 3.79
Ball Complement Size Dw (in) 0.079
Ball Complement Size Dw (mm) 2
Bore Diameter x Outer Diameter x Width (mm) 8 x 16 x 5
Max Speed Oil (x1000min -1) 47
Max Speed Grease (x1000min -1) 40
Chamfer rs (min) (in) 0.008
Chamfer rs (min) (mm) 0.20
Outer Diameter D (in) 0.630
Load Rating Cor (N) 590
Load Rating Cr (n) 1260
Width B (mm) 4.0
Outer Diameter D (mm) 16.0
• Type Ball Bearing
• Series Type 680 Series
