Specifications

AIMS SKU A0016169
Brand Sutton Tools
Model Number T9051588
Barcode Number 9311963020969
Diameter (inch) 5/8
TPI 11
Shank (mm) 12.5
L1 (mm) 102
L2 (mm) 32
z 4
Drill Size (mm) 13.5
L4 (mm) 13
Square Size (mm) 10
• Group Code T905
• System of Measurement ISO529
• Thread Form British Standard Whitworth 55 (BSW)
• Material High Speed Steel (HSS)
• Finish Bright
• Lead Taper/Intermediate/Bottoming
• Application N (for normal general purpose type materials)
• Shank Form Reinforced Shank (with square drive)
• Max Cut Depth 1xD
• Tap Type Straight Flute
• Nut Tolerance Z3 Medium
