Specifications

AIMS SKU A0016133
Brand Sutton Tools
Model Number T9031429
Barcode Number 9311963038438
Diameter (inch) 9/16
TPI 12
Shank (mm) 11.2
L1 (mm) 95
L2 (mm) 30
z 4
Drill Size (mm) 12.2
L4 (mm) 12
Square Size (mm) 9
• Group Code T903
• System of Measurement ISO529
• Thread Form UNC
• Material High Speed Steel (HSS)
• Finish Bright
• Lead Taper/Intermediate/Bottoming
• Application N (for normal general purpose type materials)
• Shank Form Reinforced Shank (with square drive)
• Max Cut Depth 1xD
• Tap Type Straight Flute
• Nut Tolerance 2B
