Specifications

AIMS SKU A0016137
Brand Sutton Tools
Model Number T9032540
Barcode Number 9311963024219
Diameter (inch) #1
TPI 8
Shank (mm) 18
L1 (mm) 130
L2 (mm) 45
z 4
Drill Size (mm) 22.2
L4 (mm) 18
Square Size (mm) 14
• Group Code T903
• System of Measurement ISO529
• Thread Form UNC
• Material High Speed Steel (HSS)
• Finish Bright
• Lead Taper/Intermediate/Bottoming
• Application N (for normal general purpose type materials)
• Shank Form Reinforced Shank (with square drive)
• Max Cut Depth 1xD
• Tap Type Straight Flute
• Nut Tolerance 2B
