Specifications

AIMS SKU A0016117
Brand Sutton Tools
Model Number T9021807
Barcode Number 9311963038452
Shank (mm) 14
L1 (mm) 112
Pitch (mm) 1.5
Drill Size (mm) 16.5
L2 (mm) 37
Sq 11.2
Diameter (metric) MF18
L4 (mm) 14
z 4
• Group Code T902
• System of Measurement ISO529
• Thread Form ISO Metric Fine (MF)
• Material High Speed Steel (HSS)
• Finish Bright
• Lead Taper/Intermediate/Bottoming
• Application N (for normal general purpose type materials)
• Nut Tolerance 2B
• Max Cut Depth 1xD
• Tap Type Straight Flute
• Shank Form Reinforced Shank (with square drive)
