Specifications

AIMS SKU A0129921
Brand Sutton Tools
Model Number E4781210
Cutting Tip (mm) 12
Overall Length (mm) 83
Shank (mm) 12
Flute Length (mm) 26
Helix Angle R45/46/44
Rad 1
Shank Tolerance h5
Sutton Designation Al
Rake Angle 15
Point Form 45° Corner Chamfer
Point Tolerance e8
Shank Form HA
• Type Endmill Harmony
• Material Sub-Micron Grade Solid Carbide (VHM ULTRA -ISO K40-K50)
• Finish Brt
• Flutes 3
• Group Code E478
• Item Type N (finishing)
