Description

Descriptions

  • Gates Multi-Speed belt provides top performance on variable speed drives
  • It adjusts itself to the pulley groove without difficulty, providing a wide range of speeds and speed ratios
  • In addition to the standard Multi-Speed belt line, special sizes (top width, thickness and angle) are available on request

Construction

  • Narrow cross-section
  • Engineered notch contour increases flexibility. The notches ensure maximum heat dispersion, considerably decreasing running temperatures.
  • Flex-Bonded tensile cords
  • Strong transverse rigidity offers high resistance to distortion of the belt in the pulley. This results in even load distribution and wear reduction.
  • Uniform composition and thickness of the undercord ensure smooth and silent running
  • Combination of these construction features gives maximum speed adjustment

Advantages

  • Maximum range of speed changes
  • High load-carrying capacity
  • Smooth machine operation
  • Exceptionally long belt life

Specifications

  • AIMS SKU A0019482
  • Brand Gates
  • Model Number 9802-10088
  • Barcode Number 5412571182279
  • Belt Code 28X9X700
  • Length (mm) 700
  • Belt Width (mm) 28
  • Depth (mm) 9
  • Type Multispeed Belt - Industrial
  • System of Measurement Metric
  • Material Flex-Bonded Polyester Cord
  • Section Others
  • Application Heavy-Duty Belt
  • Series Gates Multi-Speed Belt
SKU: A0019482

Gates 28X9X700 (9802-10088) Multi-Speed (Variable Speed) Belt

Multispeed Belt - Industrial - Heavy Duty Belt

$62.08
RRP $155.21
SAVE $93.13 (60%)
