Specifications

AIMS SKU A0177820
Brand EZO
Model Number R3-ZZ/EZO
Width (mm) 4.978
Chamfer rs (min) (mm) 0.30
Weight (Reference) 2 Shields (g) 2.61
Ball Complement Size Dw (in) 0.094
Ball Complement Size Dw (mm) 2.381
Cage Type J
Max Speed Oil (x1000min -1) 60
Max Speed Grease (x1000min -1) 51
IR Width B (in) 0.156
IR Width B (mm) 3.967
Chamfer rs (min) (in) 0.012
Outer Diameter D (in) 0.500
Bore Diameter d (in) 0.188
Bore Diameter x Outer Diameter x Width (in) 3/16 x 1/2 x 3/16"
Load Rating Cor (N) 485
Load Rating Cr (n) 1300
Width (in) 0.196
Bore Diameter d (mm) 4.762
Outer Diameter D (mm) 12.700
• Type Ball Bearing
• Series Type R Series
