Specifications

AIMS SKU A0177875
Brand EZO
Model Number 698-2RSC3/EZO
Cage Type J
Ball Complement Qty Z (pcs) 7
Width B1 (in) 0.236
Width B1 (mm) 6.0
Width B (in) 0.236
Bore Diameter d inch 0.315
Bore Diameter d mm 8.0
Weight (Reference) 2 Shields (g) 6.72
Ball Complement Size Dw (in) 0.125
Ball Complement Size Dw (mm) 3.175
Bore Diameter x Outer Diameter x Width (mm) 8 x 19 x 6
Max Speed Oil (x1000min -1) 44
Max Speed Grease (x1000min -1) 37
Chamfer rs (min) (in) 0.012
Chamfer rs (min) (mm) 0.30
Outer Diameter D (in) 0.748
Load Rating Cor (N) 912
Load Rating Cr (n) 2240
Width B (mm) 6.0
Outer Diameter D (mm) 19.0
• Type Ball Bearing
• Series Type 690 Series
