Specifications

AIMS SKU A0177841
Brand EZO
Model Number MR105-ZZ/EZO
Cage Type W
Ball Complement Qty Z (pcs) 8
Width B1 (in) 0.158
Width B1 (mm) 4.0
Bore Diameter d inch 0.197
Bore Diameter d mm 5.0
Weight (Reference) 2 Shields (g) 1.23
Ball Complement Size Dw (in) 0.047
Ball Complement Size Dw (mm) 1.2
Bore Diameter x Outer Diameter x Width (mm) 5 x 10 x 4
Max Speed Oil (x1000min -1) 71
Max Speed Grease (x1000min -1) 60
Chamfer rs (min) (in) 0.006
Chamfer rs (min) (mm) 0.15
Outer Diameter D (in) 0.394
Load Rating Cor (N) 168
Load Rating Cr (n) 432
Outer Diameter D (mm) 10.0
