Description

Deep Groove Ball Bearing Rubber Seal (C3)

  • Internal clearance, C3 greater than normal clearance.
  • Closue 2NSE9, Buna-Nitrile Rubber Light Contact Seals on Both Sides for 10 mm to 50 mm Bore.
  • Deep Groove Ball Bearings use balls to maintain separation between the inner and out bearing races.
  • Deep Groove ball bearings are the most popular of all the ball bearing types because they are available in a wide variety of seal, shield and snap-ring arrangements.
  • Deep Groove ball bearings can sustain radial, axial, or composite loads and because of simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation.

Specifications

  • AIMS SKU A0153864
  • Brand NACHI
  • Model Number 6001-2NSE9C3/NACHI
  • Basic Static Load Rating Cor (n) 2390
  • Da (min) 14
  • Factor Fo 13.2
  • Bore Diameter x Outer Diameter x Width (mm) 12 x 28 x 8
  • Basic Dynamic Load Rating Cr (n) 5100
  • Width B (mm) 8
  • Ra (max) 0.3
  • Outer Diameter D (mm) 28
  • Da (max) 26
  • Bore Diameter d (mm) 12
  • R (min) 0.3
  • Type Deep-Groove Ball Bearings
  • Series 6000 Series
SKU: A0153864 On Sale

Nachi 6001-2NSE9C3 Deep Groove Ball Bearing Rubber Seal (C3) 12 x 28 x 8mm

Deep Groove Ball Bearing Rubber Seal (C3)

$5.19
$7.41
