Specifications

AIMS SKU A0059990
Belt Width (mm) 50
Number of Teeth 44
Pitch (mm) 10
No. of Teeth 44
Outer Diameter (dd) 140.06 mm
Pitch Circle Diameter (da) 138.2 mm
Flange Diameter (dB) - mm
Width (b1) 56 mm
Overall Width (b) 66 mm
Hub Diameter (d) 88 mm
Bore Diameter (d) 16
Finished Bore Hole (max) 46 mm
Suits Belt Size (width) 50 mm
• Type Pilot Bore Timing Pulley
• Material Aluminium
• Section T10
• Pitch (mm) 10
