Description

Angular Contact Ball Bearings

  • Single row extra light, light & medium series bearings for combined radial and one directional axial load.
  • Angular contact ball bearings can sustain combined loads of simultaneously acting radial and axial loads because they have a contact angle.
  • The contact angle is defined as the angle between the line joining the points of contact between the ball and the raceways in the radial plane.

Specifications

  • AIMS SKU A0106698
  • Brand NACHI
  • Model Number 5210-2NS/NACHI
  • Bore Diameter x Outer Diameter x Width (mm) 50 x 90 x 30.2mm
  • R (min) 1.1
  • Basic Dynamic Load Rating (n) 54500
  • Basic Static Load (N) 44500
  • Limiting Speed (rpm) Grease Lubrication 5000
  • Width (b) mm 30.2
  • Type Angular Contact Ball Bearings
  • System of Measurement Metric
  • Series No. 5200 - 5300
SKU: A0106698 On Sale

NACHI 5210-2NS Angular Contact Ball Bearings 5200-2RS Series 50x 90x 30.2mm

Angular Contact Ball Bearings 5200-2RS Series

$98.75
$123.44
