Specifications

AIMS SKU A0147829
Brand FYH
Model Number P208/FYH
L1 (mm) 57
Bolt Size (mm) M14
Shaft Diameter (d) 40mm (1 1/2 - 1 9/16")
Shaft Diameter d (mm) 40
Static Load (c0r) kN 17.8
Dynamic Load (cr) kN 29.1
N1 (mm) 21
N (mm) 17
H1 (mm) 17
A0 (mm) 184
Factor Fo 14
L (mm) 184
h2 (mm) 98
H (mm) 49.2
b (mm) 49.2
A (mm) 54
S (mm) 19
A1 (mm) 137
• Type Bearing Housing
• System of Measurement Metric/Imperial
• Material Cast Iron
• Item Type Light Pillow Block
