Specifications

AIMS SKU A0147640
Brand FYH
Model Number FL208/FYH
A1 (mm) 14
S (mm) 19
A (mm) 36
b (mm) 49.2
H (mm) 175
L (mm) 100
Factor Fo 14
Bolt Size (mm) M14
A0 (mm) 51.2
A2 (mm) 21
J (mm) 144
N (mm) 16
Dynamic Load (cr) kN 29.1
Static Load (c0r) kN 17.8
Shaft Diameter d (mm) 40
Shaft Diameter (d) 40mm (1 1/2" - 1 9/16")
• Type Bearing Housing
• System of Measurement Metric/Imperial
• Material Cast Iron
• Item Type Light Two Bolt Flange
