Specifications

AIMS SKU A0104877
Brand FYH
Model Number NA206/FYH
C (mm) 19
C1 (mm) 5
Dynamic Radial Load Rating 19.5
Static Radial Load Rating 11.3
r (min) mm 1
S (mm) 18.3
S2 (mm) 6
Shaft Diameter (d) mm 30
Nominal Bearing Bore (d1) mm 44.5
Nominal Bearing Outer (D) mm 62
Nominal Inner Ring Width (B) mm 36.5
• Type Ball Bearing Inserts
• System of Measurement Metric
• Series NA200
• Item Type Eccentric Ball Bearings
