Description

Dixon Rubber Steam Hose Fabric Reinforced

Applications

  • Textile reinforced Mandrel built. Recommended for saturated steam and hot water washdown.

Features

  • Ozone resistance

Construction

  • Tube: White smooth EPDM rubber compound (in accordance with BGVV XX I Category 2)
  • Cover: White smooth (wrapped finish) EPDM rubber compound, fatty food and weathering resistant
  • Reinforcement: High strength synthetic cord

Safety Notes

  • Pressurised steam is an extremely dangerous commodity. Only hose, fittings, clamps and accessory items that have been approved for steam service should ever be used! Never use an unapproved item for steam service. Always follow the manufacturers product recommendations for pressurised steam handling.
  • Bend radius figure is calculated as theoretical

Available Lengths

  • Cut Length: 10 m
  • Coil Lenght: 20, 60 and 120 m

Specifications

  • AIMS SKU A0068458C60
  • Brand Dixon
  • Model Number A235040B060
  • Colour Black
  • Hose Length 60 m
  • Application Hot Water & Steam
  • Temperature Range -30°C to 160°C (steam), -35°C to 95°C (hot wash)
  • Weight kg/m 1.54
  • Hose ID (mm) 38
  • Bend Radius (mm) 4561
  • Hose Outside Diameter (mm) 53
  • Working Pressure Steam (psi) 87
  • Working Pressure Steam (mpa) 0.6
  • Burst Pressure Steam 870 psi
  • Working Pressure Hot Water (psi) 150
  • Type Steam Hose Fabric Reinforced
  • Material EPDM Rubber
SKU: A0068458C60

Dixon 38mm x 60m Rubber Steam Hose Fabric Reinforced Black A235040B060

Dixon Rubber Steam Hose Fabric Reinforced

$4,437.70
