Dixon 19mm x 20m Rubber Multi-Purpose Non-Conductive Hose Blue A104020BL020

Description

Dixon Rubber Multi-Purpose Non-Conductive Hose

Minimum Cut Length: 10 metres
Standard Coil Length: 20, 30 and 100 metres

Applications

Multi-Purpose hose used in steel mills, shipyards, foundries, auto plants and construction industries.
For conveying a wide range of media including air, water, oil and other petroleum products

Features

Red, Yellow, and Blue covers allow for colour coding where cross contamination of media can affect the safe operation of plant equipment.
UV Stabilised
Oil Mist Resistant
Non-Conductive

Construction

Tube: NBR
Reinforcing: Polyester Braid
Cover: NBR

***Note:

For the 200 m, there are 2 pieces of 100m tied together by string to allow spooling onto the reel. Continuous length of 200m is not available.
For the 60m, there are 2 pieces of 30m tied together by string to allow spooling onto the reel. Continuous length of 60m is not available.

Specifications

AIMS SKU A0068292C20

Brand Dixon

Model Number A104020BL020

Colour Yellow-A104020BL020

Hose Length 20 m

Application Water, Air & Chemical

Burst Pressure 1200 psi

Working Pressure (psi) 300

Temperature Range -20°C to 100°C

Working Pressure (mpa) 2.1

Weight kg/m 0.63

Hose ID (mm) 19

Bend Radius (mm) 114

Hose Outside Diameter (mm) 30.2

Type Multi-Purpose Non-Conductive Hose
Material NBR

Calculate Shipping

Resources

Technical Data Sheet

Dixon Product Catalogue
