Description

Dixon Butterfly Valve - Minsup - Iron

  • Lever operated; corrosion-resistant stainless steel disk and shaft.
  • Lever can be padlocked out in any of the 11 positions.
  • Nitrile butadiene lining is molded to the body.
  • Disc has a high flow coefficient design which minimises flow resistance and cavitation.

Specifications

  • Shouldered ends in accordance with ANSI/AWWA C606
  • Actuator mounting in accordance with AS5211

Applications

  • Mining Industry

Construction

  • Body- SG Iron to ISO 1083; 400-250-15
  • Lining- Nitrile Butadiene- 70 Duro hardness
  • Disc- Cast Stainless Steel Grade CF8M to ASTIMA351
  • Handle- SG Iron ISO 1083;400-250-15
  • Shaft- Grade 316 Stainless Steel
  • Actuator- Lever as standard

Available Options

  • Actuation available upon request
  • Optional operators include manual gearbox and pneumatic actuator

Specifications

  • AIMS SKU A0067475
  • Brand Dixon
  • Model Number 08/002/574/00
  • Size (mm) 150
  • Dimension (mm) 149 Face to Face
  • Pressure Rating (PSI) 290
  • Pressure Rating (kPa) 2000
  • Minimum Temperature (°C) -20
  • Maximum Temperature (°C) 60
  • Type Butterfly Valve
  • Material Iron
  • Item Type Shouldered Butterfly Valve
  • Seat Nitrile Butadiene Lining
SKU: A0067475

Dixon 08/002/574/00 150mm Butterfly Valve Minsup Iron

Dixon Butterfly Valve Minsup

$895.81
