Turning Insert DNMU Insert Style - FF2 Grade TP1030

  • V shape code.
  • U insert type, negative insert with hole and chip-breaker on both faces for tool holders with pin lock only.
  • TP1030 insert grade.

TP1030 Insert Grade

  • Coated highly wear-resistant cermet grade for high surface finish and productivity requirements mainly used in steels and stainless steels.
  • Ti-Al-Si-N nanolaminate coating.

FF2 Chipbreaker Programme

  • Chipbreaker for negative inserts. Intended for fine-finishing and semi-finishing of steels and stainless steels.
  • The positive, tight chip groove offers light cutting action combined with superior chip forming.
  • Indicative machining range: f = 0,08–0,30 mm/rev, ap = 0,2–1,5 mm.

About Seco Turning Insert

  • Anything is possible when it comes to our broad selection of general turning grades and chip breakers.
  • Supporting inserts of different shapes, sizes, and thicknesses, we developed each of these solutions with the same goal in mind.
  • to boost the productivity and tool life in your turning applications.
  • Covering all material groups, this comprehensive range allows you to achieve your goals in terms of material removal rates, tool life, and surface finish.

Specifications

  • AIMS SKU A0117350
  • Brand Seco
  • Model Number 2787044
  • Barcode Number 87044027001007
  • Designation DNMU110404-FF2 TP1030
  • Grade TP1030
  • Theoretical Cutting Edge Length (L) mm 11.6
  • Clearance Angle Major (an) Deg 0.0 deg
  • Corner Radius (RE) mm 0.4
  • Insert Included Angle (epsr) Deg 55.0 deg
  • Inscribed Circle Diameter (IC) mm 9.53
  • Insert Thickness (S) mm 4.76
  • Chipbreaker Programme FF2
  • Fixing Hole Diameter (d1) Mm 3.8
  • Insert Shape Code (SC) D
  • Type Turning Insert
  • Insert Style DNMU
  • Insert Grade Grade TP1030
SKU: A0117350 On Sale

Seco Turning Insert D Shape Code 4.76 x 0.4 x 9.53mm U Insert Type - FF2 Grade TP1030 ± 0.13/± 0.05mm Tolerance DNMU110404-FF2,TP1030 - Pack of 10

Turning Insert DNMU Insert Style - FF2 Grade TP1030

$169.35
$199.24
