Sutton S206 SupaTorq Hex Impact Bit, HX3 x 50mm, 2 Pack
Available
The Sutton S206 Hex bit is part of the SupaTorq range: a 1/4" hex power bit made from custom S8 steel for impact drivers, cordless drills and quick-change adaptors. SupaTorq is Sutton's range for fastener driving in trade and industrial applications.
This listing covers HX3, HX4, HX5 and HX6 tip sizes in 25, 50, 75, 100 and 150 mm lengths, supplied in packs of 2, 5 and 10.
A Torsion Zone protects the bit from breakage in high-torque applications, precision machined tips improve screw fitment with minimal cam-out, and colour bands make heads easy to identify.
Where this product is used
- Driving hex recess screws with impact drivers, cordless drills and quick-change adaptors.
- Application areas listed for the range: DIY, professional, automotive, electrical, plumbing, carpentry and plastering.
Design features
- Custom S8 steel: a custom industrial-grade steel blend for longer life.
- Torsion Zone: protects the bit from breakage in high-torque applications.
- 1/4" hex power bit shank: for use in impact drivers and quick-change adaptors.
- Precision machined tips: improved screw fitment, with minimal cam-out.
- Colour bands: colour-coded for easy head identification.
Sizes and pack options
Item numbers, tip sizes and overall lengths are shown below. Lengths are in millimetres.
| Sutton item no. | Tip size | Overall length (mm) | Pieces | Supplied as |
|---|---|---|---|---|
| S206H02B03 | HX3 | 50 | 2 | Carded |
| S206H02B04 | HX4 | 50 | 2 | Carded |
| S206H02E04 | HX4 | 100 | 2 | Carded |
| S206H02G04 | HX4 | 150 | 2 | Carded |
| S206H02A05 | HX5 | 25 | 2 | Carded |
| S206H02B05 | HX5 | 50 | 2 | Carded |
| S206H05B05 | HX5 | 50 | 5 | Carded |
| S206H10B05 | HX5 | 50 | 10 | Carded |
| S206H02D05 | HX5 | 75 | 2 | Carded |
| S206H02E05 | HX5 | 100 | 2 | Carded |
| S206H05E05 | HX5 | 100 | 5 | Carded |
| S206H10E05 | HX5 | 100 | 10 | Carded |
| S206H02G05 | HX5 | 150 | 2 | Carded |
| S206H05G05 | HX5 | 150 | 5 | Carded |
| S206H10G05 | HX5 | 150 | 10 | Carded |
| S206H02B06 | HX6 | 50 | 2 | Carded |
| S206H05B06 | HX6 | 50 | 5 | Carded |
| S206H10B06 | HX6 | 50 | 10 | Carded |
| S206H02E06 | HX6 | 100 | 2 | Carded |
| S206H05E06 | HX6 | 100 | 5 | Carded |
| S206H10E06 | HX6 | 100 | 10 | Carded |
| S206H02G06 | HX6 | 150 | 2 | Carded |
| S206H05G06 | HX6 | 150 | 5 | Carded |
| S206H10G06 | HX6 | 150 | 10 | Carded |
Key specifications
| Specification | Detail |
|---|---|
| Brand | Sutton |
| Range | SupaTorq |
| Catalogue code | S206 |
| Type | Hex |
| Tip sizes | HX3, HX4, HX5, HX6 |
| Overall length | 25, 50, 75, 100, 150 mm |
| Shank | 1/4 inch hex |
| Material | Custom S8 steel |
| Pieces per pack | 2, 5, 10 |
| Use | Impact drivers, cordless drills and quick-change adaptors |
Related Sutton bits
Compare other bits in this range: S200 SupaTorq Phillips bits, S202 SupaTorq Pozidriv bits, S204 SupaTorq Square (Robertson) bits, S212 SupaTorq Torx bits, S214 SupaTorq Torx-S security bits, S218 SupaTorq Slotted bits, S230 SupaTorq magnetic nutsetters, S235 SupaTorq magnetic bit holders.
