Seco Turning Insert V Shape Code 2.38 x 0.2 x 6.35mm T Insert Type - MF2 5° Grade CP600 ± 0.05/± 0.05mm VBMT110202-MF2 Pack of 10

Turning Insert VBMT Insert Style - MF2 5° PVD Coated


Available
$265.73
This product is available in other sizes/variants
Select another variant of Seco Turning Insert VBMT Insert Style - MF2 5° PVD Coated
Designation
Inscribed Circle Diameter (ic) Mm
Insert Thickness (S) mm
Theoretical Cutting Edge Length (l) Mm
Fixing Hole Diameter D1 Mm
Corner Radius (RE) mm

Browse other products under:
Turning Inserts
Browse other products by:
SECO

Turning Insert V Shape Code T Insert Type - MF2 5° Grade CP600

  • V shape code
  • T Insert Type.
  • 5° insert side clearance angles.

CP600 Insert Grade

  • PVD Coated.
  • Very tough micrograin grade intended for stainless steels and steels applicable but generally applicable whenever high edge toughness required e.g. more difficult interrupted cuts.
  • (Ti, Al)N + TiN.

MF2 Chipbreaker Programme

  • A versatile finishing to semi-finishing chipbreaker with light-cutting action for positive inserts.
  • Suitable for a wide range of cuts in steel and stainless steel finishing applications including boring.
  • Indicative machining range: f = 0,08–0,50 mm/rev, ap = 0,15–3,00 mm.

About Seco Turning Insert

  • Anything is possible when it comes to our broad selection of general turning grades and chip breakers.
  • Supporting inserts of different shapes, sizes, and thicknesses, we developed each of these solutions with the same goal in mind.
  • to boost the productivity and tool life in your turning applications.
  • Covering all material groups, this comprehensive range allows you to achieve your goals in terms of material removal rates, tool life, and surface finish.

AIMS SKU

A0116457

Brand

Seco

Model #

2904265

Barcode #

4265029001001

Designation

VBMT110202-MF2

Qty in Pack

10

Tolerance

ñ 0.05/ñ 0.05mm

Fixing Hole Diameter (d1) Mm

2.9

Fixing Hole Diameter D1 Mm

2.9

Insert Thickness (S) mm

2.38

Theoretical Cutting Edge Length (l) Mm

11.07

Clearance Angle Major (an) Deg

5.0 deg

Insert Shape Code (SC)

V

Grade

Grade CP600

Chipbreaker Programme

MF2

Insert Included Angle (epsr) Deg

35.0 deg

Inscribed Circle Diameter (ic) Mm

6.35

Corner Radius (RE) mm

0.2

Product Type

Turning Insert

Insert Style

VBMT

Insert Grade

Grade CP600
