Air-Operated Oil Pump Kit 1:1 ratio - 205L Drum type

Technical Specifications

• 1:1 Ratio pumps offer a higher flow rate but limited in delivery distance from drum transfer over short distances
• Suitable for oils or anti-freeze up to SAE 80 viscosity
• Output up to 40LPM, depending on viscosity
• Min/Max air pressure: 30/150psi, air inlet 1/4” BSP(F)
• Pump outlet 1/2” BSP(F), pump inlet 1” BSP(F)
• Wetted materials: steel, brass, aluminum, nitrile rubber, polyurethane and turcite
• Note: Air lubricator supplied
