KCP 1060V T20 Vertical Cover Assembly Taper Grid Coupling

Description

Vertical Split Steel Cover Taper Grid Coupling

Type V cover, vertical steel cover.
Best choice for high operating speeds.
Allows easy access to the grid spring.
Steel grid cover for strength.

*** Cover Only ****

About KCP Taper Grid Coupling

Taper Grid Couplings are recognizable due to their unique steel flexible grid running through the tapered hubs.
The benefits of the Grid Coupling are reduced vibration and shock loads.
The compact size of shaft-to-shaft couplings.
Handle torque capacity due to high strength hardened alloy steel construction
Deflect torsionally for normal shock or vibratory loads.
Capacity for misalignment without producing the detrimental side loads.
Designed with a trapezoidal cross-section and tempered for spring hardness.
Increase in strength rating and provide reserve strength for a longer part life.
Easy to fit the trapezoidal grids into the slots of the hub and short time of installation.
Free to rock, pivot, and float.

Specifications

AIMS SKU A0148888

Brand KCP

Model Number 1060V

Bore Diameter Min (mm) 19.1

Lube Wt (kg) 0.09

Cplg Wt (kg) 7.3

Gap Max (mm) 4.5

Gap Normal (mm) 3

Gap Min (mm) 1.5

Dimension E (mm) 32.2

Dimension D (mm) 76.2

Dimension C (mm) 63.5

Size 1060

Bore Diameter Max (mm) 57

Basic Torque (kg-cm) 6337

Hp Per 100 rpm 8.85

Cover Profile Vertical

Max. Speed (rpm) 6000

Dimension B (mm) 130

Dimension A (mm) 162

Type Cover Taper Grid Coupling
