Description

Descriptions

  • Heavy duty Industrial Manual Lever Block
  • Lever blocks are a versatile lifting & tensioning device widely used in rigging, construction & mining.
  • Lever blocks can be used in any direction but must be in a straight line.
  • The Beaver lever block has a chain guide fitted in order to stop the load from jumping out of the pockets on the load sprocket.
  • The Beaver 3S Industrial Chain Lever Block mechanism and gears are enclosed in a robust all steel compact shell.
  • The load chain is made of high resistance, Grade 80 Alloy Steel, black finish, heat-treated, calibrated and marked according to International Standards ISO 3077 and ISO 1834.
  • All Beaver lever block gears are fitted with industrial Roller bearings.
  • The short arm lever and the gear ratio allows minimum effort to raise maximum load with maximum security.
  • The top and bottom hooks come complete with cast latches.
  • Top and bottom hooks are fitted with ball bearings to allow rotation under load.
  • Ergonomic and heavy free knob to ensure easy and convenient handling.
  • Machined and heat-treated gears, offering better durability and longer life cycle.
  • Every Beaver 3S Industrial Lever Block is operationally tested to its rated capacity and is supplied with a Beaver test certificate, relating to its stamped identification side plate.
  • Beaver ‘ID’ plates and rivets are supplied in stainless steel (a non-conductive material) in order to avoid dangerous sparking, making them ideal for underground mining.
  • A comprehensive range of spare parts are available, complete with full repair facilities and re- testing to Australian Standard specifications.

Safety Features:

  • Colour Coded to Match International Lifting Standard

Applications: Lifting

Material: Aluminium

Approved Standards: AS 1418.2

Specifications

  • AIMS SKU A0102684
  • Brand Beaver
  • Model Number 506080
  • Barcode Number 9322297079202
  • Load Capacity (kg) 800
  • Lift Height (m) 1.5
  • Number Of Falls 1
  • Length Of Lever (mm) 280
  • Headroom (mm) 325
  • Test Load (kg) 11.3
  • Cable Diameter 6 x 18
  • Product Colour White
  • Effort To Lift Full Load 140
  • Group Code 506025
  • Barcode 9322297079516
  • Material Heat Treated Alloy Steel
  • Grade 80
SKU: A0102684

Beaver 3S G80 Industrial Manual Lever Block - 1.5m x 800kg MRC (White)

Beaver 3S G80 Industrial Manual Lever Block

$214.80
