Austlift Eye Bolt DIN580 Zinc Plated M6
Regular price
$1.36
Sale price
$1.36
Regular price
Inc. GST
Available
End fittings match standard hook, eye, fork and chain terminations, allowing the screw or eye bolt to be substituted into existing rigging without modification. Suited to wire rope and rigging tensioning, lifting eye attachment points, tent and marquee tension assemblies, marine and yacht rigging, and crane and lifting accessory attachment. Drop-forged alloy steel construction and traceable WLL marking deliver the load performance lifting and structural applications demand. Built for repeat service across trade, marine and industrial rigging.
Where this product is used
- Eye bolt lifting points on machinery covers, gearboxes, and pump assemblies.
- Equipment and plant maintenance lifting points for overhead hoists.
- Threaded lifting point installation on motors, drives, and housings.
- Structural member lifting attachment using eye bolt assemblies.
- Precast concrete and formwork lifting point installation.
- Building and infrastructure equipment and fixture lifting.
Key specifications
| Product Type | Rigging Hardware |
| Standard(s) | DIN 580 |
Working Load Limit by size
| Size / Variant | WLL (t) |
|---|---|
| M6 | 0.09 |
| M8 | 0.14 |
| M10 | 0.23 |
| M12 | 0.34 |
| M16 | 0.7 |
| M20 | 1.2 |
| M22 | 1.5 |
| M24 | 1.8 |
| M27 | 2.5 |
| M30 | 3.6 |
| M36 | 5.1 |
| M42 | 7 |
| M48 | 8.6 |
| M56 | 11.5 |
Product Highlights
Couldn't load pickup availability
Payment & Security
Payment methods
Secure Checkout. We do not store credit card details
Available Options:
-
M6
Model Number: 601006
-
M8
Model Number: 601008
-
M10
Model Number: 601010
-
M12
Model Number: 601012
-
M16
Model Number: 601016
-
M20
Model Number: 601020
-
M22
Model Number: 601022
-
M24
Model Number: 601024
-
M27
Model Number: 601027
-
M30
Model Number: 601030
-
M36
Model Number: 601036
-
M42
Model Number: 601042
-
M48
Model Number: 601048
-
M56
Model Number: 601056
